LYNGDORF 3400

INTEGRATED AMPLIFIER AND AUDIO PROCESSOR - With extreme audio processing options combined with the most powerful and advanced digital amplifier technology, the TDAI-3400 is the most powerful product from Lyngdorf Audio yet marketed.

A BUILT-IN MEDIA PLAYER

The TDAI-3400 accepts all media interfaces and features a built-in media player with the highest playback quality. Through your local network or via the USB connectors, you can access your entire library of music through the DLNA/UPnP enabled player. This media player also connects to streaming services like Roon Ready, Spotify Connect, and Airplay as well as internet radio.


CONTROL TDAI-3400 WITH AN APP

The Lyngdorf Remote Application automatically discovers the TDAI-3400 connected to your local network, and you will be able to adjust all the basic functions like input selection and volume level from your handheld device.

The built-in media player can be controlled directly, and you can access music files stored on pen drives connected to the Lyngdorf TDAI-3400 as well as search all files stored on your local hard drives. Swiping left and right gives you access to cover art as well as informing you of the signal resolution.

The Lyngdorf Remote Application is available for free download from both IOS and Android.



THE BEST SOUND IN THE OPTIMAL ROOM

Through the web interface you can perform all setup and operations from the menu system, which allows you to tailor your setup and sound, and the digital crossover allows 3 individual output settings.With our proprietary RoomPerfectTM room-correction software to eliminate the negative influence of the listening room, the TDAI-3400 delivers a perfect sound without the need for extensive room treatment.

THE ROOM – THE WEAKEST LINK IN THE SOUND CHAIN

Most high-end products are developed in sonically-ideal listening rooms with optimized dimensions and acoustic treatments. However, in reality, sound systems are installed in authentic living spaces, not sound labs.

Your sound system should be perfect in your environment—and only Lyngdorf Audio can promise it will be. Here’s the situation: all designs of audio electronics and speakers specify a frequency response with 2 or 3 dB—but your room might incur peaks and dips of more than 20 dB throughout the frequencies, which can ruin the performance of even the best audio designs. And here’s the answer: Lyngdorf Audio’s RoomPerfect™, the end product of more than two decades of pioneering audio research and development.


CONNECT AUDIO AND VIDEO SOURCES

A variety of inputs and outputs provide plenty of options to connect your audio and video sources as well as your speaker setup.

  • 7 digital inputs including a balanced AES/EBU
  • USB inputs connects to music stored external
  • 2 analog inputs for simple analog music sources
  • Optional module with 4 high-end analog inputs
  • Optional module with 3 HDMI inputs and 1 HDMI output

TECHNICAL DETAILS

Description:
2-channel integrated amplifier and audio processor
Power handling:
2×400 W RMS @ 4Ohm / 2x200W RMS @ 8Ohm
Standard digital inputs (asynchronous):
1 x AES-EBU (≤192kHz/24bit), 2 x Coaxial (≤192kHz/24bit), 3 x Optical (≤96 kHz/24bit), 1 x USB B (≤384kHz/32bit, ≤DSD128, DXD)
Standard analog inputs:
2 x Analog Single Ended RCA (Max level: 4.0V = 0dBFS), 1 x Microphone input for RoomPerfect™ calibration
HDMI module (optional in-/output):
1 x HDMI Output / 3 x HDMI Inputs (PCM ≤192kHz/24bit), ARC (PCM ≤192 kHz/24bit), CEC integration, HDMI 2.0a support, HDCP 2.2, Resolutions requiring 600 MHz clock supported
High-end analog input module:
3 x single ended RCA, 1 x balanced XLR
Standard outputs:
1 x Stereo Analog RCA, 1 x Stereo Analog XLR, 1 x Stereo Digital Coax, 1 x Headphone 3,5mm
Audio specifications:
Frequency Response: ±0,5dB from 20 to 20,000 Hz, Total Harmonic Distortion: 0.05% max from 20 to 20,000 Hz, THD-N 1w/8ohm 0,04% / THD-N 1w/4ohm 0,04%
Mediaplayer:
Roon Ready, Spotify Connect, DLNA Support (uPnP) Airplay, Local file playback (USB), Internet Radio (vTuner)
Wireless connections:
Bluetooth (4.2 BLE), Wi-Fi (802.11 n/ac)
Trigger (12V):
1 x Input, which can be related to audio inputs, 1 x Output
3.5mm jack / Thresholds approx.: On: 2.4V Off: 1.6V
Control interfaces:
Web-interface, IP Control, 1 x DB9 connector for RS232 control, 1 x RJ45 Ethernet LAN connector, 2 x USB connectors (Type A) , SD card slot (Backup of filters and settings)
Accessories included:
RoomPerfect™ Microphone, Microphone stand, cable & mini-jack connector, Remote control (IR / BLE)
Placement options:
Optional rack mount or freestanding
Dimensions (Wx H x D):
45 x 10.5 x 36 cm (including connectors) / 17.7 x 4.1 x 14.1 inches
Weight:
8.2 kg / 18.1 lb
Finish:
Matte black
